Common File Formats in Apache Spark: CSV, JSON, Avro, and Parquet

Understanding file formats commonly used in apache spark

Introduction

Apache Spark supports multiple file formats for reading and writing data, each optimized for different use cases. Choosing the right format can dramatically impact storage costs, query performance, and overall system efficiency.

In modern data engineering, the file format decision isn’t just about compatibility. It’s about optimizing for your workload patterns: Are you writing data once and reading it many times? Do you need schema evolution? Are you processing entire rows or just specific columns?

This guide explores the four most common file formats in Spark ecosystems: CSV, JSON, Avro, and Parquet. Understanding their strengths and trade-offs will help you make informed decisions that can reduce query times from minutes to seconds and cut storage costs by over 95%.

Core Concepts

CSV (Comma-Separated Values)

Row-based plain text format where each line represents a record, and commas separate field values.

Key Characteristics

1. Human-readable and universally supported

2. No built-in schema definition (schema must be inferred or specified)

3. Minimal compression capabilities

4. Fast to write but slow to read at scale

5. No support for nested data structures

Performance

1. Fastest write times among all formats

2. Poor compression ratio (minimal size reduction)

3. Inefficient for large-scale analytics due to lack of optimization

Example

# Reading CSV in Spark

df = spark.read.csv(”data.csv”, header=True, inferSchema=True)
df.write.mode(”overwrite”).csv(”output.csv”)

JSON (JavaScript Object Notation)

Text-based format that represents data as key-value pairs, supporting nested and hierarchical structures.

Key Characteristics

1. Self-describing schema (schema stored with each record)

2. Excellent for semi-structured and nested data

3. Human-readable and web-friendly

4. Schema flexibility without predefined structure

5. Largest storage footprint due to schema repetition

Performance

1. Stores schema attributes with every row, leading to significant overhead

2. Poor compression efficiency

3. Slower read/write compared to binary formats

4. Ideal for data exchange, not long-term storage

Example

from pyspark.sql.functions import col

# Reading JSON in Spark
df = spark.read.json(”data.json”)

# Writing JSON
df.write.mode(”overwrite”).json(”output.json”)

# Handling nested structures
df.select(col(”user.name”), col(”user.email”)).show()

Avro (Row-Based Binary Format)

Row-oriented binary format developed by Apache, designed for data serialization with embedded schema support.

Characteristics

1. Row-based storage (entire records stored sequentially)

2. Schema stored separately in header (not with each row)

3. Excellent schema evolution support

4. Efficient serialization/deserialization

5. Compression ratio: ~91%

Performance Profile

1. Superior write performance (best for streaming)

2. Efficient for operations requiring entire row reads

3. Optimized for append-heavy workloads

4. Less efficient for column-specific queries

Use Cases

1. Kafka streaming pipelines

2. Real-time data ingestion

3. Systems requiring frequent schema changes

4. Cross-platform data exchange

Example

# Reading Avro in Spark (requires spark-avro package)
df = spark.read.format(”avro”).load(”data.avro”)

# Writing Avro
df.write.format(”avro”).mode(”overwrite”).save(”output.avro”)

Parquet (Columnar Binary Format)

Columnar storage format where data is organized by columns rather than rows, optimized for analytical queries.

Characteristics

1. Columnar storage (data from same column stored together)

2. Advanced compression techniques (dictionary encoding, run-length encoding, bit-packing)

3. Predicate pushdown and column pruning support

4. Compression ratio: ~97.5%

5. Spark’s default format

Performance

1. Read times up to 3x faster than Avro for analytical queries

2. Slower writes compared to row-based formats

3. Exceptional compression (194GB CSV → 4.7GB Parquet in benchmarks)

4. Efficient I/O when accessing subset of columns

Optimization

1. Only required columns are read from disk

2. Statistical metadata enables partition pruning

3. Compatible with most big data frameworks (Spark, Hive, Presto, Snowflake)

Example

# Reading Parquet in Spark
df = spark.read.parquet(”data.parquet”)

# Writing Parquet with compression
df.write.mode(”overwrite”).option(”compression”, “snappy”) .parquet(”output.parquet”)

# Column pruning - only reads required columns
df_subset = spark.read.parquet(”data.parquet”).select(”id”, “amount”)

# Partitioning for better query performance
df.write.partitionBy(”date”, “region”).parquet(”partitioned_output.parquet”)

Key Takeaways

• CSV: Fast writes, human-readable, poor compression. Use for debugging only.

• JSON: Handles nested data, terrible storage efficiency. Use for API ingestion, then convert.

• Avro: Row-based, fast writes, 91% compression. Best for streaming and real-time ingestion.

• Parquet: Columnar, 97.5% compression, 3x faster reads. Default choice for analytics.

• Hybrid approach: Ingest with Avro, store and analyze with Parquet for optimal performance.

• File format impacts: Storage costs, query performance, and system scalability.
